BOE LCD Video Wall
HomeLCD Video WallBOE LCD Video Wall>BOE 65 inch splicing screen 3.5mm LCD splicing screen large size 4K HD display s

BOE 65 inch splicing screen 3.5mm LCD splicing screen large size 4K HD display s

Time:2022-11-24Popularity:123

BOE LCD splicing screen - KAWDEN official website
  • BOE 65 inch splicing screen 3.5mm LCD splicing screen large size 4K HD display s
Product description

KAWDEN 65 inch splicing screen 3.5mm LCD splicing screen large size 4K HD display

KAWDEN 65 inch splicing screen 3.5mm LCD splicing screen large size 4K HD display

KAWDEN 65 inch splicing screen 3.5mm LCD splicing screen large size 4K HD display

KAWDEN 65 inch splicing screen 3.5mm LCD splicing screen large size 4K HD display

KAWDEN LCD splicing screen Seamless LCD splicing screen Large size 4K HD display

KAWDEN 65 inch splicing screen 3.5mm LCD splicing screen large size 4K HD display

KAWDEN splicing screen brand manufacturer long team strategic part

our corporate clients

brand strength of Kawden

Honorary Qualification Certificate


Technical Parameters
Specification and model
KD-S65035BL
LCD panel and size
BOE LCD panel 65 inches
Butt joint
less than3.5mm
Display area(mm) 1428(H)×803(V)
display mode
16:9
Liquid crystal type
LED
Maximum resolution
1920*1080
Display color
16.7M
Point spacing(mm) 0.63(H)*0.63(V)
Brightness
500cd/㎡
contrast ratio
4000:1
Angle of view (up/down/left/right)
178°/178°/178°/178°
response time
8ms
Field frequency
60HZ
Composite video input
5-way BNC (BNC * 5) input
Composite video output
2-way BNC (BNC * 2) output, connected to video equipment, etc
Serial port control/RS232 input One RS232-RJ45 (568B) input
Serial port control/RS232 output One RS232-RJ45 (568B) output
VGA input 1-channel D-SUB VGA input
HDMI 1 channel HDMI input
DVI 1 channel DVI input
Color system
1 channel DVI input
Compatible HD TV input
480P,576P,720P,1080I,1080P
3D comb filtering
yes
noise reduction
yes
Menu language (optional)
中文/English
Power Supply
AC100V~240V,50/60Hz
Maximum power loss
≤300W
Standby power loss
<1W
Cooling system
Ultra quiet dual fan cooling, with temperature control function
Casing material
Strong metal casing
Body size (length × high × Thick)
1428(W)×803(H)×200(D)mm
Installation method
Wall mounted/cabinet/floor/front maintenance support
parts

Wall bracket, power cord, remote controller, 232 to RJ45 serial port connector, mounting

screw (M8 * 16), software manual, warranty card, certificate of conformity

Consulting Service
Users in the course of any problems encountered, can call the free consultation Tel: 0755-21042483 Advisory
Replacement Service
Replacement period of the product, if there is indeed due to factory quality problems caused by the reasons, the user can go to the dealer free of charge.
Warranty Service
Warranty period of the product, if a quality problem, can go to the local after-sales service center to enjoy the warranty service.
Maintenance Service
Maintenance period of the product, if a quality problem, the user can go to the local after-sales service center or commissioned by the dealer for repair services.
