SamSung LCD Video Wall
HomeLCD Video WallSamSung LCD Video Wall>55 inch DID Samsung LCD multi screen splicing screen conference room display spl

55 inch DID Samsung LCD multi screen splicing screen conference room display spl

Time:2022-11-23Popularity:46

Supply Samsung LCD splicing screen manufacturer KAWDEN
  • 55 inch DID Samsung LCD multi screen splicing screen conference room display spl
Product description

1、 Samsung LCD Multi screen Mosaic Screen Features

Cardiff 55 inch Samsung splicing screen has 3.5mm splicing seam, and the display has built-in self splicing function. Through simple settings, multiple LCD screens can be spliced. one thousand nine hundred and twenty × 1080 full HD display resolution can provide the dispatching center with very clear and delicate display images, and display HD signals without compression. With 178 degree wide viewing angle technology, you can see the superior display effect from any side. LED backlight is adopted, with wide color gamut, good color performance, low energy consumption, and safer low-voltage.



2、 Samsung LCD multi screen splicing screen function


LCD multi screen splicing screen is a complete LCD splicing display unit, which can be used either as a display alone or as a large LCD splicing screen. According to different use needs, realize the function of variable large screen: single screen split display, single screen separate display, arbitrary combination display, full screen LCD splicing, vertical screen display, and image frame can be compensated or covered.



3、 Application of samsung lcd multi screen splicing screen
Application sites: security, hotels, shopping malls, finance, transportation, water conservancy, government, electricity, medical, energy, television media, enterprises and institutions, etc.
Technical Parameters
Specification and model KD—sx5535dx
Panel size
55"
Butt joint
less than 3.5mm
Display Area
1209.5(H)×680.4(V)
display mode
16:9
Liquid crystal type
LED
Maximum resolution
1920x1080
Display color
16.7M
Point spacing(mm) 0.0.63(H)*0.63(V)
Brightness(nits) 500cd/㎡
contrast ratio
4000:1
Angle of view (up/down/left/right)
178°/178°/178°/178°
response time
8ms
Field frequency
50HZ、60HZ、70HZ、
Composite video input
5-way BNC(BNC*5)input
Composite video output
2-way BNC (BNC * 2) output, connected to video equipment, etc
Serial port control/RS232 input
1-way RS232-RJ45(568B)input
Serial port control/RS232 output
1-way RS232-RJ45(568B)output
VGA input 1-way D-SUB VGA input
HDMI 1-way HDMI input
DVI 1-way DVI input
Color system
PAL/NTSC/automatic recognition
Compatible HD TV input
480P,576P,720P,1080I,1080P
3D comb filtering
yes
noise reduction
yes
Menu language (optional)
中文/English
Power Supply
AC100V~240V,50/60Hz
Maximum power loss
≤300W
Standby power loss
<1W
Cooling system
Ultra quiet dual fan cooling, with temperature control function
Casing material
Strong metal casing
Body size (length × High)
1213(W)×684(H)×136(D)mm
Installation method
Cabinet/wall mounted/suspended
Packaging accessories

Wall bracket, power cord, remote controller, 232 to RJ45 serial port connector, mounting screw (M8 * 16),

software manual, warranty card, certificate of conformity
