KAWDEN ALL-IN-ONE—INTELLIGENCE DISTRIBUTION LCD VIDEO WALL
Time:2020-12-09Popularity:3287
All-in-one cloud synchronization LCD video wall connect to screen through LVDS port, suitable to Samsung LG panel perfectly, support back-light and parameter adjustment.
All IP camera signal and local DVI/HDMI/VGA signal can transfer to screen directly, can display control and manage images easily without the external equipment like matrix、signal lines、or distributor etc, this is the large different from the traditional video wall connect mode, images is no delay between the transmission and display, really reach cloud synchronization.
功能特点:
图片:
Features:
1.Cloud synchronization technology solve the problem of out-sync in cloud splicing and network decoding
2.Progressive edge brightness technology
Progressive edge brightness tech solve the problem of black edge
3.Full back-up system
Centralization、distribution、centralization-distrobition back-up, can integrate traditional and distribution back-up system.
4.Powerful decoding function
Support 1080P×2 60Hz 1080P×4 30Hz 720P×9 DI×16’s decoding function, achieve signal of RTSP ONVIF
5.Internal mixed matrix function
Every unit can accept signal of IP、HDMI、DVI、VGA、Ypbpr、CVBS、USB, flexibly display image on every unit of the screen.
6.Unit support driving 1920×1080
7.Input LVDS×1 stereo audio signal input
Panel Size | 40inch | 46inch | 47inch | 48inch | 49inch | 55inch |
Pezel | 12mm | 3.9mm | 4.9mm | 8mm | 2.8mm | 1.8mm |
Brightness | 500cd/m2 | 700cd/m2 | 450cd/m2 | 500cd/m2 | 500cd/m2 | 500cd/m2 |
Max resolution radio | 1920*1080 | 1920*1080 | 1920*1080 | 1920*1080 | 1920*1080 | 4096*2160 |
Aspect Ratio | 16:09 | 16:09 | 16:09 | 16:09 | 16:09 | 16:09 |
Response Time | 8ms | 8ms | 8ms | 8ms | 8ms | 8ms |
Color | 16.7M | 16.7M | 16.7M | 16.7M | 16.7M | 16.7M |
Contrast ratio | 3000:01:00 | 3000:01:00 | 4000:01:00 | 4000:01:00 | 3000:01:00 | 4000:01:00 |
Max power consumption | ≤180W | ≤250W | ≤300W | ≤250W | ≤300W | ≤400W |
Standby power consumption | <1W | <1W | <1W | <1W | <1W | <1W |
Pixel Pitch | 0.46*0.46 | 0.63*0.63 | 0.54*0.54 | 0.54*0.54 | 0.63*0.63 | 0.63*0.63 |
Voltage input | AC100V~240V,50/60Hz | |||||
Bachlight life | ≥60000 hours | |||||
Visual Angle (H/V) | 178°/178°/178°/178° | |||||
Field frequency | 50Hz、60Hz、70Hz | |||||
HD TV output | 480P、576P、720P、1080P、4K | |||||
Packing dimension | 、1315.3mmx786.3mmx314.7mm | |||||
Installation mode | Wall-mounted/built-in cabinet/floor-standing | |||||
Accessories list | Power cable/main signal line/232 to RJ45 serial port/install screws(M8*16)/software manual/warranty card/certification card |
