LG LCD Video Wall
HomeLCD Video WallLG LCD Video Wall>49 inch LCD multi screen splicing display low brightness, energy saving and envi

49 inch LCD multi screen splicing display low brightness, energy saving and envi

Time:2022-11-23Popularity:333

LG LCD splicing screen | | lg splicing screen KAWDEN
  • 49 inch LCD multi screen splicing display low brightness, energy saving and envi
Product description

1、 Introduction to 49 inch multi screen splicing screen


The 49 inch LCD splicing screen adopts LG industrial level LCD panel, combined with ultra narrow edge splicing technology, signal switching technology, lossless remote transmission technology, and image splicing processing technology to form a set of LCD splicing display system with diversified functions, intelligent control, and advanced operation, to show customers high-quality crystal splicing images with high brightness, high definition, and no interference. With professional anti burning screen and heat dissipation technology, MTBF reaches 60000 hours. The perfect seamless splicing effect can minimize the visual blind spot and sense of visual separation of the viewer, and present you with an integrated grand vision and ultra clear and shocking dynamic visual experience.



2. 49 inch multi screen splicing screen function


The 49 inch ultra narrow edge LCD splicing screen can be used either as a display alone or as a large screen splicing wall. According to different use needs, it can realize the functions of variable large screen: single screen split display, single screen separate display, arbitrary combination display, full screen LCD splicing, double splicing LCD splicing, vertical screen display, image frame can be compensated or covered, support roaming, zooming stretching, cross screen display of digital signals, setting and operation of various display plans, and real-time processing of full HD signals.


3. 49 inch multi screen splicing screen application


The 49 inch LCD splicing wall is widely used in: video monitoring, traffic control, security monitoring, national defense, stage entertainment, television studio, stock securities, large exhibitions, shopping malls, banks, office halls, corporate welcome screens, specialty stores, dispatching command, etc.
Technical Parameters
Model     KD-S49035dl
Panel size
49"
size 1084.0mm*615.0mm
Screen resolution
1920×1080P
Activate display area
1087mm(W)*619mm(H)
Color saturation
97%
brightness
500 cd/㎡
contrast ratio
4000:01:00
refresh frequency
120Hz
Display Color
10bit – 1 billion colors
Viewing angle
178°
Total joint at both sides
≤8mm
Input interface
Chromatic aberration component, VGA,DVI,HDMI,AV
Signal format
NTSC、PAL、480P、576P、720P、1080I、1080P
control interface
  Infrared remote controller and RS232
image processing techniques

The first company to create "dynamic super resolution technology", which can make low pixel images appear clearly in the full HD display screen;

De interlacing processing technology to eliminate flicker; De interlacing algorithm to eliminate "sawtooth";
Dynamic interpolation compensation, 3D dynamic digital noise reduction, 3D comb filtering, 10 bit digital brightness and color enhancement,

automatic skin color correction, 3D motion compensation, nonlinear scaling and other international leading technologies

Processing technology; Image frame can be compensated or covered, and full HD signal can be processed in real time.

Overview of display functions

Manual/timing/cruise/alarm plan setting, kaleidoscope demonstration, intelligent temperature control and alarm, automatic detection of

communication failure and other functions, multi signal split screen display, full screen display, arbitrary combination display

working temperature
0-40 ℃
Operating humidity
15-75%
Power Supply AC220V
Average power consumption 200W
weight
Single piece 35kg, double piece: 67kg wooden frame about 20kg
Installation method
Wall mounted, embedded, floor mounted cabinet, hoisting, TV cabinet
Recommended place of use

Security, command center, entertainment industry, enterprise exhibition, advertising media, exhibition center, factories and mines, power,

water conservancy, education, government agencies, military, etc

Consulting Service
Users in the course of any problems encountered, can call the free consultation Tel: 0755-21042483 Advisory
Replacement Service
Replacement period of the product, if there is indeed due to factory quality problems caused by the reasons, the user can go to the dealer free of charge.
Warranty Service
Warranty period of the product, if a quality problem, can go to the local after-sales service center to enjoy the warranty service.
Maintenance Service
Maintenance period of the product, if a quality problem, the user can go to the local after-sales service center or commissioned by the dealer for repair services.
